Sirio CELL 918 Mariner Dual-Band GSM Base Antenna

$65.00

Add to Cart:



  • Model: cell918
  • Shipping Weight: 1lbs
  • 10 Units in Stock
  • Manufactured by: Sirio Antenna

Dual-band marine antenna conceived for CELLULAR systems working on GSM 900 & 1800 MHz, DCS 1.9, DECT and UMTS. All metallic components are made of chromium plated brass and stainless steel to improve its strength. It's inserted in a glass fibre tube for a perfect protection against the worst sea climates. It can be supplied with the following fixing mounts: “M-3” adjustable mount of chromium plated brass, “M-8” adjustable mount of white nylon and “M-10”adjustable mount of chromed plated brass.



Features:

  • Marine antenna, Dual-band
  • Unity-gain, Omnidirectional
  • Perfect protection against the worst weather conditions
  • Protection from static discharges DC-Ground
  • Chrome-plated brass ferrule
  • 180° inclination and adjustable whip
  • Supplied with white coaxial cable RG-58 C/U directly connected
  • For GSM 900 & 1800,PCN,DECT and UMTS systems

    Electrical Data

  • Type: 1/2λ dipole
  • Frequency range: 880-960 MHz & 1700-2170 MHz for GSM 900 & 1800,PCN,DECT and UMTS systems
  • Impedance: 50Ω
  • Radiation (H-plane): 360° omnidirectional
  • Radiation (E-plane): beamwidth @ -3 dB = 50°
  • Radiation angle: 0°
  • Polarization: linear vertical
  • Gain: 0 dBd - 2.15 dBi
  • SWR in bandwidth: ≤ 2
  • Max. power (CW) @ 30°C: 20 Watts
  • Standard mount: "M-8" NY
  • Cable length / Type: 5 m / white RG 58
  • Connector: FME-female

    Mechanical Data

  • Materials: Materials: Chromed Brass, Fiberglass, Nylon
  • Height (approx.): 420 mm
  • Weight (approx.): 470 gr
  • Operating temperature: -20° C to +80° C



  • This product was added to our catalog on Sunday 03 February, 2013.
